DMS Series Integrated Biological Microscope

ALLTION OFFERS ONE-STOP-PURCHASING FOR MICROSCOPES

DMS-651 Compound Digital LCD Inverted Biological Microscope
Digital Parts	Model	DMS-651
	Camera	12 Megapixels
	Photo Resolution	4000X3000
	Video Resolution	1280X720/30FPS
	LCD Screen	9 HD Inches LCD Screen Resolution: 1280X 800
	Data Output	HDMI/USB HD Output
	Menu Language	Nine: English, German ,French, Spanish, Russian, Japanese, Korean, Latin, Arabic)
	Measurement & Positioning	Crosshair and Arrow (Black, White, Red, Green, Blue)
	Storage	4G SD Card
	Data Mode	Year, Month, Day, Hour, Minute
Optical Parts	View Head	Compensation Free Binocular Head, Inclined 30。 Interpupillary Distance 55-75mm
	Eyepiece	High-point, Extra Wide Field Eyepiece EW10×/18
	Objective	LWD Infinite Plan Objective	4×/ 0. 1,WD 18mm
			40×/ 0.6,WD 2.6mm

		Infinite Plan Phase Objective		PH10×/ 0.25,WD 10 mm
				PH20×/ 0.4,WD 5. 1mm
	Nosepiece	Quintuple Nosepiece
	Condenser	ELWD Condenser NA 0.3, LWD 72mm (Without Condenser 150mm)
	Annulus	10× 、20× 、40× Phase Annulus Plate
	Stage	Plain Stage 160×250mm,
		Glass Insert
		Auxiliary Stages 70×180mm
	Focusing	Coaxial Coarse & Fine Adjustment Vertical Objective Movement Coarse Stroke 37.7mm/ Rotation Fine Stroke 0.2mm/ Rotation
	Illumination	LED Illumination
	Filter	Diameter 45mm, Blue, Green and Ground Glass
Optional Parts	Objective	LWD Infinite Plan Objective	10×/ 0.25, WD 10mm
			20×/ 0.4, WD 5. 1mm
		Infinite Plan Phase Objective	PH40×/ 0.65, WD 0.35mm
	Centering Telescope	Centering Telescope (Φ30MM)
	Phase Annulus	10× 、20× 、40× Phase Annulus Plate
	Stage	Attachable Mechanical Stage, X-Y Coaxial Control，Moving Rang 120×78mm
		Terasaki Holder
		Φ38mm Petri Dish Holder
		Φ54mm Slide Glass Holder

DMS-653 Compound Digital LCD Biological Microscope
Digital Parts	Model	DMS-653
	Camera	12 Megapixels
	Screen Resolution	1280X800
	Video Resolution	1080P/30FPS
	LCD Screen	9 HD Inches LCD Screen Resolution: 1280X 800
	Data Output	HDMI/USB HD Output
	Menu Language	Nine: English, German, French, Spanish, Russian, Japanese, Korean, Latin, Arabic.
	Measurement & Positioning	Coordinates and Arrow (Black, White, Red, Green, Blue)
	Storage	4G SD Card
	Date Mode	Year, Month, Day, Hour, Minute

Optical Parts	Viewing Head	Compensation Free Binocular Head, Inclined 30°, Interpupillary Distance 55-75mm
	Eyepiece	Wide Field Eyepiece WF10×/ 18mm
	Objective	Infinity Achromatic 4X, 10X,40X (Spring), 100X (Spring, Oil)
	Nosepiece	Quadruple
	Stage	Double Layers Mechanical Stage: 140mmX140mm Moving Range: 75mmX50mm
	Focusing System	Coaxial Coarse & Fine Focus System with Tension Adjustable, Limit Stopper ,Range 24mm, Fine Division 0.002mm
	Illumination	3.7V,3W LED Lamp Brightness Adjustable
	Condenser	NA1.25 Abbe Condenser with Iris Diaphragm & Filter Rack & Pinion Adjustment
	Filter	Blue and Green Filter
Optional Parts	Eyepiece	Wide Field Eyepiece WF16×/ 11mm
	Dark Field Attachment	Dark Field Condenser (Dry) NA0.7-0.9
	Dark Field Attachment	Dark Field Condenser (Wet) NA1.25-1.36

DMS-654 Compound Digital LCD Biological Microscope
Digital Parts	Model	DMS-654
Digital Parts	Photo Resolution	12 Megapixels
	Video Resolution	1080/30FPS
	LCD Screen	9 HD Inches LCD Screen Resolution1280 X 800
	Data Output	USB/HDMI HD Output
	Menu Language	Nine: English, German, French, Spanish, Russia, Japanese, Korean, Latin, Arabic.
	Measurement & Positioning	Crosshair and Arrow (Black, White, Red, Green, Blue)
	Storage	4G SD Card
	Date Mode	Year, Month, Day, Hour, Minute
Optical Parts	Viewing Head	Compensation Free Binocular Head, Inclined 30° Interpupillary Distance 55-75mm
	Eyepiece	Larger Viewing Area with Wide Field Eyepiece W10×/ 18 Focus Control with Diopter Adjustable
	Objective	Infinity Plan Achromatic 4×/10×/40×/100×
	Nosepiece	Backward Quintuple Nosepiece
	Condenser	Swing-out Condenser NA 0.9/ 0.25
	Stage	Double Layers Mechanical Stage: 185mm×142mm Moving Range: 75×55mm
	Illumination	External Illumination, Aspherical Collector, LED illumination
	Filter	Green & Blue Filter
Optional Parts	Objective	Infinity Plan Achromatic 20×
	Objective	Objectives for Dark Field 100×
	Phase Contrast Kit	Turret Phase Contrast Kit

	Dark Field Attachment	Dark Field Condenser (Dry)
		Dark Field Condenser (Oil)

DMS-655 Compound Digital LCD Biological Microscope
Digital Parts	Model	DMS-655P	DMS-655BP
	Camera	12 Megapixels
	Photo Resolution	4000X3000
	Video Resolution	1280X720/30FPS
	LCD Screen	9 HD Inches LCD Screen Resolution: 1280X 800
	Data Output	HDMI/USB HD Output
	Menu Language	Nine: English, German,French,Spanish,Russia, Japanese, Korean, Latin, Arabic)
	Measurement & Positioning	Coordinates for Measurements and Arrow (Black,White, Red, Green, Blue)
	Storage	4G SD Card
	Date Mode	Year, Month, Day, Hour, Minute
Optical Parts	Viewing Head	Compensation Free Binocular Head, Inclined 30 ° Interpupillary Distance 55-75mm
	Eyepiece	Wide Field Eyepiece WF10×/ 18
	Objective	Infinitive Plan Achromatic Objectives 4X /10X /40X /100X
	Nosepiece	Quadruple Nosepiece
	Focusing	Coaxial Coarse and Fine Adjustment Moving Range 20mm
	Illumination	3W LED
	Stage	Double Layers Mechanical Stage: 140mm×140mm Moving Range: 75mm×50mm
	Condenser	Sliding-in Centerable Condenser NA12.5

Items and specification subject to change,

please contact ALLTION for current product information
