Main Characteristics: the pupil distance can be adjusted by one center knob, it is very simple and convenient for user.
Main Characteristics: the pupil distance can be adjusted by one center knob, it is very simple and convenient for user.
Mainly technical specification:
Item No. | Magnification | Optical System | Working distance | Viewing Angle | Field of View | Weight |
ACM250 | 2.5X | Compound Optics | 200-600mm | Adjustable | 100-110mm | 42g |
ACM300 | 3X | Compound Optics | 280-600mm | Adjustable | 75-85mm | 46g |
ACM350 | 3.5X | Compound Optics | 280-600mm | Adjustable | 60-65mm | 47g |
ACM400 | 4X | Prism Optics | 280-600mm | Adjustable | 70-75mm | 65g |
● There are 4 kinds of working distance are optional: Short(S):280-380mm, Regular(R):360-460mm, Long(L):440-540mm,Extra long(XL):200-300mm
● We can provide waterproof loupes for ACH series, such as ACHF2.5X,ACHF3X,ACHF3.5X
